Circular die-cutting line detection, stacking and paper delivery device
Mainly used for cutting and removing printed products after die-cutting
Key words:
camera
package
germany
detection
Classification:
Automatic detection of production line
Hotline:
Circular die-cutting line detection, stacking and paper delivery device
Graphic Details
It is mainly used for the elimination of printed products after die cutting, as well as the collection, sorting and palletizing output of printed products.
1. Daily chemical package, medicine package, electronic package, liquid package, roof package, food package, etc.).
2. Printing on-line inspection system: the front single 8K camera detects printing defects, such as color difference, printing leakage, overprinting deviation, mosquitoes and flies, foreign bodies, etc. The reverse double 4K camera detects mosquitoes and flies, foreign bodies, film defects, etc.
Installation Diagram of Die-cutting Online Detection System
Main configuration of detection system
Name | Manufacturer | Specifications and models | Quantity |
color camera | Germany | High speed 8k line scanning | 1 |
Black and white camera | Canada | La-cm-04K08A | 2 |
Industrial Lens | Long Trail | Schneider 60mm, Long Trail 35mm | 3 |
detection software | Beijing lead | Miscan 5000 dongle | 1 |
industrial computer | Taiwan Advantech | Genuine IPC-i7-6700K-Win10 | 1 |
acquisition card | Germany | ACL | 2 |
LCD Display | Dell | 27 inches | 3 |
Encoder | Germany | 1024 line | 1 |
Encoder line | Germany | 10 meters long | 1 |
Camera power cord | American North Branch | 8 meters long | 3 |
Camera data cable | American North Branch | 8 meters long | 4 |
bright light source | Beijing lead | Length 816mm | 2 |
Light source power supply | Beijing lead | LP250W | 2 |
Light source power cord | Beijing lead | 8 meters long | 2 |
Industrial air conditioning | Shanghai Quanrui | 500W | 1 |
Inspection of main electrical cabinet | Beijing lead | 700*700*1100 | 1 |
Camera shield | Beijing lead | cBOX-0000-01 | 3 |
signal synchronizer | Beijing lead | IO-Web-V1.1 | 1 |
Warning lamp | United States | Red, Green, Sound | 1 |
Cooling fan | Taiwan | DC24V | 3 |
Wireless keyboard and mouse | Logitech | MK240 | 1 |
USB extension cable | Outsourced | 2 meters long | 2 |
Power Cord | Outsourced | 2 meters long | 6 |
Other Consumables | Outsourced |
| 1 |
Installing the structure frame | Homemade | sBOX-0000-02 | 2 |
Toolbox | Outsourced |
| 1 |
